Ground Screws for PV Module Ground Mounts
- Product Type: solar ground mounting screws
- Product Model: SPC-solar-screws-A20
- Material: Carbon Steel
- Max Wind Load : 60 m/s
- Max Snow Load : 1.4 KN / M 2
- Application: Soft Soil Ground Solar Panels Installation
Product Description :
This ground screws model SPC-solar-screws-A20 is specially designed for solar panel ground mounting .
The solar ground anchors with flange is very suitable for wide range of soft soid and ground circumstance : sand, earth, marsh, desert
, outdoor signs… Offer strong foundation supports .
By using Q235 standard carbon steel material and hot dipped galvanized finished , this fixed flange solar ground screws is anti-rusty,
anti-corrosion for more than 10 years .
| Pile | Flange | |||||
| PipeDia | Width | Thickness | Length | Flange Dia | Width | Thickness |
| (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) |
| φ48 | 56 | 6 | 1000/1500/2000 | φ180 | 60 | 6 |
| φ76 | 56/76 | 6月8日 | 1000/1500/1800/2000/2500 | φ180/φ200 | 80 | 6 / 8 |
| φ89 | 95 | 10 | 1500/1800/2000/2500/3000 | φ200 | 100 | 10 |
| φ114 | 115 | 10 | 1500/2000/2500/3000 | φ200 | 120 | 10 |
| φ140 | 145 | 10 | 1500/2000/2500/3000/3500 | φ220 | 150 | 10 |
Features :
– custimized ground screw length for solar panels accepable : 600mm, 800mm, 1000mm, 1200mm, 1600mm, 1800mm, 2000mm,
2500mm, 3500mm …
–
3.0 mm wall thickness in default, special requirements available such as 2.5mm, 2.75mm,3.25mm, 3.5mm, 4.0mm …
– Several flange types for ground screws like :D180x8mm, D200x8mm, D220x8mm can be choosing, several hole patterns available .
– 20 years life guarantee ;
– Strong Steel Pallet Packing , suitable for shipping by sea ;
– This ground screws can be also used for fencing, street lamps, camping tents, wood house … besides solar panel ground installation.
– Easy and fast drilling by piling machine, handheld machine or by two hands
| Brief Descriptions : | |
| Fixed Flange Ground Screws for solar mounting racking, solar panels ground installation | |
| Item type: | Solar Ground Screws SPC-solar-screws-A20 |
| Technical Parameters : | |
| Installation Site : | solar panel ground mounting |
| Profile Material : | Q235 Carbon Steel |
| Surface processing : | Hot dipped galvanized |
| Length : | 1.8 m, 2.0 m, 2.2 m, 2.5 m, customized |
| External diameter : | 76 mm ( 3″) |
| Wall thickness : | 3 mm ( 0.12″) |
| Connector : | Flange |
| Flange diameter : | 180 mm 200mm 220mm 240mm 250mm |
| Flange thickness : | 8 mm |
| Application : | Solar power mounting, ground base, fences, carport, mobile house and flag poles. |
| Standards : | AS/NZS 1170 |
| DIN 1055 | |
| GB50009-2012 | |
| IBC2009 | |
| TUV | |
| JIS C 8955 : 2011 | |
| International Building Code IBC 2009 | |
| California Building Code CBC 2010 | |
| Warranty | 10 years |
| Designed Life Span | 20 years |
| Packing Details : | |
| Inner : | shrinkable wrap |
| Outer : | Iron plate |
Fixed flange Ground Screw wholesale factory
Q:
Hi, I am interested in your solar grouding screws.
Please provide cost, with shipping cost to:80516 zip code.
A:
Nice to know that you are interested in our ground screws.
We are Ground screw wholesale factoty with more than 10 years experience.
Carry some types of groud screws, may I know which type and size you need.
ground screw for solar panel
Q:
I need the item: Fixed flange ground screw A20, 1800mm, how much for 800 pcs.
fixed flange ground screw wholesale factory
A:
Base on 800 in quantity, I have sent the price to your email.
Thank you.
Fixed flange Ground Screw supplier
” Hi,
Please contact me for the supply for the fixed fangle ground screw.
We need big quantity for a new proejct.”
“Hello Umut
Nice to get your inquiry for our fixed fangle ground screw.
Please kindly let us know how many quantity you need,
and which type of the ground screw do you prefered?
FYI.
Some of our hot sale items:
Fixed flange Ground Screw supplier”
” Please give me your best offer for the ground screw type F for 5000 Nos. for the first order.”
“We received, please refer to our quotation as file attached.
Any question just let me know.
Thank you!
Fixed flange Ground Screw supplier sales team
Can ground screws be customized ?
Can ground screws be customized for solar mounting project ?
Yes, if our client has a large solar power for installing, we can tailor base on drawing sizes ,
following is one of our customized screw pile case .
