Solar Mounting waterproof M rails
- Product Type: Solar mounting rail
- Product Model: SPC-R-130
- Material: ZAM275 & Steel
- Max Wind Load : 60 m/s
- Max Snow Load : 3.6 KN / M 2
- Solar Module Orientation: Landscape / Horizontal
- Application: Unframed / Bifacial / Frameless modules
Product Description:
The PV Waterproof Rail is made of high quality ZAM275 material with the performance of high load-bearing, wind resistance,ensure the safety of solar panels.
And the PV Waterproof Rail secure the solar panels and hold them strongly and waterproof, Besides, the PV Waterproof Rail have many holes in the sides before shipment so the rails can be mounted fast and flexibly by adjusting the installation place.
What’s more, customized the solar PV Waterproof Rail is welcome, we make make it as per your request.
L=3000mm
L=4000mm
L=5000mm
L=6000mm
Features of this PV Waterproof Rail:
(1) Strong wind and snow resistance;
(2) Waterproof and sturdy The new structure is waterproof, equipped with water guide grooves, lower maintenance costs and longer life.
Easy to install.;
(3) Fast and flexible installation;
(4) Effectively prevent corrosion and oxidation
(5) Ventilation and heat dissipation
Good ventilation and heat dissipation performance to ensure good power generation efficiency of components.
Our Solar PV Waterproof Rail have a dual role as both a rail and a water channel and gutter
Welcome to contact us anytime, our company website: www.solarpartscomponents.com
| Datasheet | |
| Description: | |
| Galvanized steel water channel rails | |
| NO.： | SPC-R-130 |
| Product Type: | Solar mounting rail |
| Installation location: | Water channel/gutter/ rail |
| Installation angle: | 0-60 degrees |
| Material : | ZAM275 & Steel |
| Module: | Frame solar Module |
| Warranty: | 10 Years |
| Lifetime: | 20 Years |
| Orientation： | Landscape,Portrait |
| Wind speed： | 60 M/s |
| Snow load： | 3.6 KN / M2 |
| Height; | Above 2m |
| Standard: | AS/NZS1170 & DIN 1055 |
Waterproof Solar Rail structure Main parts
The Waterproof Solar Rail for solar panels specially designed for solar installation. The material of the rail is Galvanized zinc aluminum magnesium material, high-quality material and meeting the standards of strength testing, it can withstand extreme environments, including strong wind and strong snow loads. We provide guide rails of different materials to facilitate customers’ choices. It is very easy to use bolt fixing method to create an installation system that fully meets the requirements of the specification. It can save a lot of time and money.
waterproof rail for roof
The Waterproof Solar Rail structure Main parts including:
- Waterproof rail
- U-shaped channel
- Rail connection
- End clampkits
- Mid clampkits
- Top Cover
waterproof rails
Solar waterproof photovoltaic PV mounting solution by M rail
waterproof water channel
This waterproof support product is applicable to:
Application of M-type rail
Our new M-type rail can be used with any purlins, beams and square pipes. It can be used as a rail and a water guide. One rail has two functions and has holes on the side for easy fixing and installation. This M rail is larger than ordinary rails and has a strong load-bearing capacity. The special design makes this gutter have good drainage performance.
The picture below is our M-type rail used in the customer’s roof awning, 100% waterproof, and has become the most important part of the customer’s roof sun room
solar PV mounting rail
It is one of the Shared-Rail Mounting System. In the shared-rail system, for 2 panels, you’ll need just 3 rails. The panels will use one rail in middle and 2 rails on the edge. This technique reduces solar panel installation time along with cost. It also creates fewer holes in your roof.
Solar PV Waterproof rails inquiry
Q：interested in your waterproof rails. Do you have real photo? Availability?
A: Thank you for your kind feedback, I have sent the quotation and project reference through your email, please check.Looking forward to your reply.
Solar PV Mounting Waterproof Rail
PV Waterproof solution for frameless panel
PV waterproof solution structrue
And the PV Waterproof solution for frameless panel secure the solar panels and hold them strongly and waterproof, Besides, the PV Waterproof Rail have many holes in the sides before shipment so the rails can be mounted fast and flexibly by adjusting the installation place.
- Overview
-
Product Description:
The PV Waterproof Rail is made of high quality ZAM275 material with the performance of high load-bearing, wind resistance,ensure the safety of solar panels.
And the PV Waterproof Rail secure the solar panels and hold them strongly and waterproof, Besides, the PV Waterproof Rail have many holes in the sides before shipment so the rails can be mounted fast and flexibly by adjusting the installation place.
What’s more, customized the solar PV Waterproof Rail is welcome, we make make it as per your request.
L=3000mm
L=4000mm
L=5000mm
L=6000mmFeatures of this PV Waterproof Rail:
(1) Strong wind and snow resistance;
(2) Waterproof and sturdy The new structure is waterproof, equipped with water guide grooves, lower maintenance costs and longer life.
Easy to install.;
(3) Fast and flexible installation;
(4) Effectively prevent corrosion and oxidation
(5) Ventilation and heat dissipation
Good ventilation and heat dissipation performance to ensure good power generation efficiency of components.
Our Solar PV Waterproof Rail have a dual role as both a rail and a water channel and gutter
Welcome to contact us anytime, our company website: www.solarpartscomponents.com
- Specification
-
Datasheet Description: Galvanized steel water channel rails NO.： SPC-R-130 Product Type: Solar mounting rail Installation location: Water channel/gutter/ rail Installation angle: 0-60 degrees Material : ZAM275 & Steel Module: Frame solar Module Warranty: 10 Years Lifetime: 20 Years Orientation： Landscape,Portrait Wind speed： 60 M/s Snow load： 3.6 KN / M2 Height; Above 2m Standard: AS/NZS1170 & DIN 1055 - FAQ
-
Waterproof Solar Rail structure Main parts
The Waterproof Solar Rail for solar panels specially designed for solar installation. The material of the rail is Galvanized zinc aluminum magnesium material, high-quality material and meeting the standards of strength testing, it can withstand extreme environments, including strong wind and strong snow loads. We provide guide rails of different materials to facilitate customers’ choices. It is very easy to use bolt fixing method to create an installation system that fully meets the requirements of the specification. It can save a lot of time and money.
waterproof rail for roof
The Waterproof Solar Rail structure Main parts including:
- Waterproof rail
- U-shaped channel
- Rail connection
- End clampkits
- Mid clampkits
- Top Cover
waterproof rails
Solar waterproof photovoltaic PV mounting solution by M rail
The M waterproof support solution is a structural installation form of waterproof support, which has many advantages over butyl tape, sealant strip and other waterproof methods:1. The guide rail with water tank has good drainage performance and waterproof effect;2. The material is S350GD+ZM275 steel, with long service life;3. Easy to install, no need to glue;4. Later maintenance costs are low and almost no maintenance is needed.
waterproof water channel
This waterproof support product is applicable to:
Residential balcony photovoltaic sunshade;Commercial photovoltaic waterproof vehicle shed;Roof waterproof system of color steel tile workshopSolar waterproof carport canopy packing lots solutionsApplication of M-type rail
Our new M-type rail can be used with any purlins, beams and square pipes. It can be used as a rail and a water guide. One rail has two functions and has holes on the side for easy fixing and installation. This M rail is larger than ordinary rails and has a strong load-bearing capacity. The special design makes this gutter have good drainage performance.
The picture below is our M-type rail used in the customer’s roof awning, 100% waterproof, and has become the most important part of the customer’s roof sun room
solar PV mounting rail
It is one of the Shared-Rail Mounting System. In the shared-rail system, for 2 panels, you’ll need just 3 rails. The panels will use one rail in middle and 2 rails on the edge. This technique reduces solar panel installation time along with cost. It also creates fewer holes in your roof.
Solar PV Waterproof rails inquiry
Q：interested in your waterproof rails. Do you have real photo? Availability?
A: Thanks for inquiry. This solar mounting rail is very strong and can be matched with any project to achieve waterproofing and I have sent more informations and photos through your email, please check.Q: This would be the best. Would you please send me the approximate cost and turn around time to receive materials or have it installed.A: Ok, Please tell me the length and quantity for the rails so that I can check the cost and the times.Q: How much cost for 10000 meters waterproof rails?A: Thank you for your kind feedback, I have sent the quotation and project reference through your email, please check.Looking forward to your reply.
Solar PV Mounting Waterproof Rail
PV Waterproof solution for frameless panel
The PV Waterproof solution for frameless panel is made of high quality material with the performance of high load-bearing, wind resistance,ensure the safety of solar panels.
PV waterproof solution structrue
And the PV Waterproof solution for frameless panel secure the solar panels and hold them strongly and waterproof, Besides, the PV Waterproof Rail have many holes in the sides before shipment so the rails can be mounted fast and flexibly by adjusting the installation place.
Features of the PV Waterproof solution for frameless panel:(1) Strong wind and snow resistance;(2) Waterproof and sturdy The new structure is waterproof, equipped with water guide grooves, lower maintenance costs and longer life.Easy to install.;(3) Fast and flexible installation;(4) Effectively prevent corrosion and oxidation(5) Ventilation and heat dissipationIt can replace the color steel tile to be directly used as the roof material to ensure that the roof will not leakage .This is the best way solutions to solve the problem of water leakage in distributed photovoltaic projects. - Video
-
Solar PV waterproof rails are innovative mounting systems designed to support solar panels while ensuring protection from water and environmental elements. These rails are particularly useful in various installations, including residential rooftops, commercial buildings, and outdoor solar farms.Waterproof Design: Engineered to prevent water accumulation and penetration, protecting the solar panels and electrical components.ApplicationsResidential Solar Installations:Ideal for rooftops where water drainage and protection from the elements are critical.Commercial Buildings:Suitable for various commercial properties, providing a reliable mounting solution for solar systems.Outdoor Solar Farms:Effective in large-scale solar installations, ensuring durability and protection against environmental factors.ConclusionSolar PV waterproof rails are a vital component in modern solar installations, providing a secure and durable solution for mounting solar panels. Their waterproof design and robust materials ensure longevity and reliability, making them an excellent choice for both residential and commercial applications. By enhancing the performance and lifespan of solar energy systems, these rails contribute significantly to the effectiveness of renewable energy solutions.
