Good quality aluminum Solar ground mounting structure are widely used for PV solar panel installation .
High efficient but competitive than steel structures .
The Aluminum Solar ground mounting structure is highly anti-corrosion and the most aesthetic structure for ground. Our Alu Ground Mounting is applicable for open field, it can be installed for residential or commercial project. The SPC-GA20-4H-CA, A type Aluminum Solar ground mounting structure is the most economical solution if the design tilt angle below 30 degree. High pre-assembled makes install efficient and easy.
Utilized AL6005-T6 material, the supporting footing is delivered with highest pre-assembly to unfold at site. The optimized design is carried out by experienced engineers to offer different joints according to different site conditions. lt can use ground screw or concrete foundations, and achieve variable inclination and height makes plant design flexible.
The benefits of Aluminum Solar ground mounting structure
-Ecological and low-maintenance for entire life span Ground screws and concrete foundations optional Pleasing aesthetics , high recycle value
– Highly pre-assembled before shipment really simplify for easy installations.Corrosion resistant and light-weight ensured by Aluminum structure
– Wide range of rails and different joints design for site conditions
Technical Parameters For this Aluminum Solar ground mounting structure:
| Installation Site : | Ground / Flat roof |
| Installation Angle : | 0-30° |
| Profile Material : | Al6005-T5 |
| Fasten Parts : | SUS 304 / A2-70 Stainless Steel |
| Small Components : | AL 6005& Stainless Steel |
| Color : | Silvery or according to customer requirements |
| Wind Load : | 60 m / s ( 130 mph ) |
| Snow Load : | 1.4 KN / M2 |
| PV Modules : | Frame, Frameless solar Module |
| Module Orientation : | Portait and Landscape |
| Warranty | 10 years |
| Designed LifeSpan | 25 years |
| Packing Details : | |
| Inner : | Bubble bag+inner box+Carton |
| Outer : | Wooden Box, Steel Pallet, MDF, etc |
