Frameless bifacial (glass-glass) panels waterproof structure
- Product Type: Unframed Solar Racking
- Product Model: Waterproof structure
- Material: ZAM275 & Steel/Aluminum/ Stainless Steel
- Max Wind Load : 60 m/s
- Max Snow Load : 3.6 KN / M 2
- Solar Module Orientation: Landscape / Horizontal
- Application: Unframed / Bifacial / Frameless modules
Describe:
Nowadays,more and more people install solar modules on roof for more cost effective. Our Waterproof structure for bifacial fameless solar panels is an ideal and popular solution, provide waterproof and more better appearance for solar roof mounting.
Waterproof is an important thing for roofing, our Waterproof structure for bifacial fameless solar panels can prevent the roofing from water leakage well. The M shape channel is made of ZM275 material which is more corrosion resistant and cost effective than HDG materials.
And the new clamps are wider than before so it is more solid and stable.
Support 2-12mm thickness of solar panel.
Put bolt head in the hollow part to avoid shading on thin panels
Fixed EPDM rubber sliding off problem.
Anodized silver or electrophoresis black optional
It is an simple and easy installation for Waterproof structure for bifacial fameless solar panels. First, fix the M shape channels on the beam,then the aluminum fixing clamps are mounted on the M shape channel and attach to the bifacial modules with our bifacial clamps to fasten the solar panels tightly.
Features of the Waterproof structure for bifacial fameless solar panels
Easy and fast to mount;
Waterproof solution;
Good appearance Good quality and reasonable price;
Suits for residential and commercial solar roof mounting
Welcome to contact us anytime, our company website: www.solarpartscomponents.com
| Datasheet | |
| Description: | |
| Waterproof structure for bifacial fameless solar panels | |
| NO.： | SPC-SPCFW |
| Product Type: | Waterproof structure |
| Installation location: | Pitched metal roof/flat roof/ground mounting/carport |
| Installation angle: | 0-60degrees |
| Material : | ZAM275 & Steel/Aluminum/ Stainless Steel |
| Module: | Frame less solar Module |
| Warranty: | 10 Years |
| Lifetime: | 20 Years |
| Orientation： | Landscape,Portrait |
| Wind speed： | 60 M/s |
| Snow load： | 3.6 KN / M2 |
| Standard: | AS/NZS1170 & DIN 1055 |
Is it the Solar waterproof structure for solar panel also suitable for framed double-sided solar panel installation?
Yes, the Solar waterproof structure for solar panel support framed/frameless double-sided solar panel installation. Just use different mid clamps and end clamp. For frameless solar panel, will be used with frameless/ thin film clamps. For framed solar panel, just use regular solar mid clamp and end clamp.
More detialed please refter to the link: https://www.solarpartscomponents.com/solar-waterproof-structure-for-solar-panel
What do you know about the Waterproof Solar structure?
Waterproof Solar structure for Pergola greenhouse
Waterproof mounting system benefits
solar waterproof structure for roof
Solar Waterproof Structural Mounting
Solar Waterproof Structural Mounting
Our Solar waterproof structure engineered for open filed projects. Both aluminium series and galvanized steel series are available.
Why use our waterproof structure?
solar waterproof structure for roof
The entire waterproof structure can be made of ZAM275 steel as the base material, and the surface is treated with galvanized magnesium-aluminum materials. If the anti-corrosion requirements are very high, aluminum alloy materials can also be selected.
waterproof structure project
Our waterproof structure has many advantages. It selects M-type water flume, fast drainage and good waterproof. The waterproof structure is safe and reliable, in line with the double standards of photovoltaic and building protection. It has strong corrosion resistance, high hardness, good wear resistance, the surface has self-repair. And it wide range of applications, suitable for a variety of photovoltaic roof waterproof application scenarios.
Why structural waterproofing?
Solar waterproof rail
waterproofing rail
For the installation of rooftop solar power plants, “waterproofing” has to be said to be a very important factor! As the world’s leading manufacturer of solar mounting system, TBS Solar explained how to deal with the waterproof problem when the solar mounting bracket is installed on the roof!
waterproof structure
Application of Waterproof structure
Waterproof structure solar systems are mostly used in rooftop solar systems. We supply and design small, low-cost waterproof structures for all types of rooftop solar systems. Customized and prefabricated turnkey solar waterproofing structural solutions available in a variety of sizes and configurations.
waterproof structure
Details of waterproof structure :
By increasing the Horizontal and Vertical Waterproof Structure, the waterproof design is carried out from the structure, which avoids the risk of leakage caused by the aging of rubber strips in the market, and truly achieves the waterproof effect of more than 25 years.
waterproof system sample
Q: What materials are used for Solar waterproof Structure?
A: The waterproof Structures are made from Galvanized steel zinc aluminum magnesium（ZAM275）material and SUS304 materials. These materials have excellent corrosion resistance.
Q: How long is the duration of Solar waterproof Structure?
A:Our Solar waterproof Structure can be used more than 20 years.
Q: What information is required if you need to design a Solar waterproof Structure?
A:The dimensions, layout, tilt angle of the solar panels, Max wind speed and snow load on project site.
Q: What is the difference between a waterproof structure and a non-waterproof ?
A: A waterproof structure includes drain rails that collect rainwater from the roof to prevent it from infiltrating other parts of the roof structure, and safely channel it away.
Q: Do you have installation instructions?
A: Yes, but there may be slight differences between different design. You can contact us to get specific instructions when you get the materials.
Q: Why wind speed and snow load are necessary for design？
A:Because we need to analysis the load data of the whole waterproof structure and make sure it is strong enough to endure all kinds of weather conditions.
Q: If I’m not very satisfied with your design, can I request to make a modify?
A: Sure. It would be better if you can provide us with your specific plan or required material list.
In order to provide an exact waterproof structure solution with you, we need to collect below information from you:
- The dimension of solar panel: length, width and thickness?
- Solar panel layout/ array?
(how many panels in a row, how many panels in a column? How many solar panels in total?)
- Module Orientation: Portrait(Vertical) / Landscape (Horizontal)?
- Wind load on project site?
- Snow load on project site?
